The screw top pressure valve test bench is a classic, reliable, and economical valve testing equipment. It adopts the principle of mechanical spiral force amplification, which drives the screw through the motor to generate strong axial thrust force, pushes the sealing pressure plate to compress and seal the tested valve, thus conducting the strength test and sealing performance test of the valve shell. This device plays an important role in valve testing, maintenance workshops, and budget limited situations due to its simple structure, easy maintenance, and high cost-effectiveness.

Product features and advantages

Simple structure, sturdy and durable: pure mechanical structure, extremely low failure rate, easy maintenance, long service life.

Intuitive operation and easy to master: No complex hydraulic or electrical knowledge is required, ordinary workers can operate and maintain it.

The clamping force is huge and stable: the mechanical self-locking characteristic ensures that once clamped, it will not loosen due to vibration during the testing process, and the clamping force is stable and reliable.

Extremely low maintenance cost: no need for hydraulic oil, no risk of hydraulic leakage, simple and low-cost replacement of spare parts.

Technical performance and feature

◆Top cylinder valve test bench is suitable to have a test for various connection types of valves, we advise you equip”servo control system”

◆Top screw valve test bench is suitable to have a test for inner tunnel sealing valves, if a user selects plane orwelded groove sealing valves, you need to choose bootstrap tank system;

◆Test medium is water or air(6 bar gas source supplied by customer,test medium water can be recycling), can bechanged over by pipeline control valve;

◆Equipped LP water filling、 HP water filling and pressure-keeping & timing auto-control system;

◆Equipped automatic oil pressure discharge system, when being ready state, system discharge automatically, whenworking, system return to normal status to effectively reduce oil temperature, elongate life of the test bench andsave energy;

◆Hydraulic pressing device (top screw) has safety interlock with water pressure discharge;

◆Customer can choose the functions as followed: Touch screen computer monitoring system;Servo controlsystem; Bootstrap tank system.

Main technical parameters and sizes
